SC Bar "Leadless" (LL) Semiconductor Strain Gages
The Piezo-Metrics SC line of semiconductor strain gages are fabricated using our newest technological process for our "P" doped bulk silicon. By design, this process produces Precision_Matched™ SC Bar strain gages with superior gage-to-gage matching in terms of reduced Gage Factor (GF) and Temperature Coefficient of Resistance (TCR) variabilities and increased dimensional uniformity across the entire lot. Our ability to offer the Precision_Matched™ SC Bar strain gages in a leadless (LL) configuration allows for unique gage applications where leadless configuration is desired.
Key Specifications
- Available gage length: 0.060 in. long
- Gage resistance: 500 Ohm
- Operating strain: +/-2000u inch/inch (+/-3000u inch/inch max.)
- Typical Gage Factor: 140
- Typical TCR: 25%/100°F
- Linearity: better than 0.25%
- Precision_Matched™ gage set matching: up to 16 gages
- Precision_Matched™ Lot Testing Metrics data: available
- Custom packaging: available – consult factory
